Industrial Metallic and Cleanable Filters

Metallic and cleanable filters are essential in a variety of industries where clean fluids, gases, or air are critical to the system’s performance, safety, and longevity. By being reusable, they offer both economic and environmental benefits.

Connectors: Standard connector(such as 222,220,226),fast connector,threaded connector,flange connector,bars,special customized connector.

Application:
1.Polyester,filament,short silk,film production polymer melts in the filtering;
2.High temperature gas,steam filtration;
3.High temperature liquid,viscous liquid filtration.

All candles are provided with internal volume reduces to avoid stagnant flow regions within the candle design. Flow diverter features within the volume reducer provide good distribution over the candles as the polymer enters the housing.

Using our range of high strength, highly permeable stainless steel fibre media, results in candle filters with low initial pressure drops and long on-stream life.

Typical applications

• Polyester bottle chip

• Polyester fibre

• Cellulose acetate fibre

• Nylon 6 and 66 fibre.

Features and benefits

• Proven robustness for cleaning and repeat use

• Long filter life

• Operate in high temperature environments

• High carbon resistance

• High filtration area for pleated candle version.

Sintered Metal Powder Cylindral Elements Specification List:




Filtration accuracy(μm)	Air-permeability(L/min •dm²)	Bubble pressure point(pa)	Porosity	Dirt holding capacity(mg/cm²)	Thickness(mm)
5	47	6600	75	5	0.54
7	63	5000	76	6	0.54
10	105	3700	77	6	0.54
15	140	2450	79	7	0.54
20	280	2000	80	13	0.54
25	360	1500	78	19	0.54
30	520	1230	79	34	0.54
40	670	960	79	34	0.54
60	1300	650	85	36	0.54

Metallic and Cleanable Filters

  A range of cleanable metallic filter cartridges and elements, which are used in the following industries:

• Aerospace and Defence

• Nuclear

• Food and Beverage

• Pharmaceutical

• Industrial Process

• Chemical Process

• Polymer.

The robustness of design, that is provided by a fully welded metallic element or cartridge, is required to resist deterioration in harsh operating environments, including aggressive conditions, high temperatures or where the operating differential pressures are high.
